Aggregate Throughput (Default)
| 1.5Gbps
| 1 Gbps
| 500 Mbps
| 200 Mbps
| 100 Mbps
| 50 Mbps
| 35Mbps
|
Aggregate Throughput (Performance License)
| 3Gbps
| 2 Gbps
| 1 Gbps
| 400 Mbps
| 300 Mbps
| 100 Mbps
| 75 Mbps
|
Aggregate CEF Only[5]Throughput (Boost License)
| Over 7Gbps
| Over 4Gbps
| Over 4Gbps
| Over 2Gbps
| Over 2Gbps
| 1.5Gbps
| 1.2Gbps
|
Total onboard WAN or LAN 10/100/1000 ports
| 4
| 4
| 4
| 3
| 3
| 2
| 2
|
Total onboard WAN or LAN 10Gbps ports
| 2
| -
| -
| -
| -
| -
| -
|
RJ-45-based ports
| 4
| 4
| 4
| 3
| 2
| 2
| 2
|
SFP-based ports
| 4
| 4
| 4
| 3
| 2
| 1
| 1
|
Enhanced service-module slots
| 3
| 2
| 0
| 2
| 1
| 0
| 0
|
Doublewide service-module slots
| 2
| 1 (assumes no singlewide SM-X modules installed)
| 0
| 1 (assumes no singlewide SM-X modules installed)
| 0
| 0
| 0
|
NIM slots
| 3
| 3
| 3
| 3
| 2
| 2
| 2
|
OIR (all I/O modules)
| Yes
| Yes
| Yes
| Yes
| Yes
| Yes
| No
|
Onboard ISC slot
| 1
| 1
| 1
| 1
| 1
| 1
| No
|
Default memory double-data-rate 3 (DDR3) error-correction-code (ECC) DRAM (Combined control/services/data planes)
| NA
| NA
| NA
| 4 GB
| 4 GB
| 4 GB
| 4GB
|
Maximum memory DDR3 ECC DRAM (Combined control/services/data planes)
| NA
| NA
| NA
| 16 GB
| 16 GB
| 8 GB
| 4GB
|
Default memory DDR3 ECC DRAM (data plane)
| 4 GB
| 2 GB
| 2 GB
| NA
| NA
| NA
| NA
|
Maximum memory DDR3 ECC DRAM (data plane)
| 4 GB
| 2 GB
| 2 GB
| NA
| NA
| NA
| NA
|
Default memory DDR3 ECC DRAM (control/services plane)
| 8 GB
| 4 GB
| 4 GB
| NA
| NA
| NA
| NA
|
Maximum memory DDR3 ECC DRAM (control/services plane)
| 32 GB
| 16 GB
| 16 GB
| NA
| NA
| NA
| NA
|
Default flash memory
| 8 GB
| 8 GB
| 8 GB
| 4 GB
| 4 GB
| 4 GB
| 8GB
|
Maximum flash memory
| 32 GB
| 32 GB
| 32 GB
| 16 GB
| 16 GB
| 8 GB
| 8GB
|
External USB 2.0 slots (type A)
| 2
| 2
| 2
| 2
| 1
| 1
| 1
|
USB console port -type B mini (up to 115.2 kbps)
| 1
| 1
| 1
| 1
| 1
| 1
| 0
|
Serial console port - RJ45 (up to 115.2 kbps)
| 1
| 1
| 1
| 1
| 1
| 1
| 1 (combo CON/AUX port)
|
Serial auxiliary port - RJ45
(up to 115.2 kbps)
| 1
| 1
| 1
| 1
| 1
| 1
| 1 (combo CON/AUX port)
|
Power-supply options
| Internal: AC, DC and PoE
| Internal: AC, DC and PoE
| Internal: AC, DC, and PoE
| Internal: AC, DC and PoE
| Internal: AC,DC and PoE
| External: AC and PoE
| External AC only
|
Redundant power supply
| Internal: AC, DC and PoE
| Internal: AC, DC and PoE
| Internal: AC, DC, and PoE
| N/A
| N/A
| N/A
|
