[JZ331A]HPE Aruba Networking AP-534 (RW) External Antennas Wi-Fi 6

SALE

HPE Aruba Networking AP-534 (RW) Dual Radio 4x4:4 802.11ax External Antennas Wi-Fi 6

SKU: AP-534 (JZ331A)

Instant Access Points ( IAP ไม่ต้องใช้ Controller สามารถทำงานแบบ Stanalone ได้)

Hardware Spec

• Four (female) RP-SMA connectors for external dual band antennas (A0 through A3, corresponding with radio chains 0 through 3). Worst-case internal loss between radio interface and external antenna connectors (due to diplexing circuitry): 0.8 dB in 2.4 GHz and 1.3 dB in 5 GHz
• Up to 1024 associated client devices per radio, and up to 16 BSSIDs per radio
• Maximum (worst-case) power consumption: DC powered: 23.3W /PoE powered (802.3bt or dual 802.3at): 26.4W /PoE powered (802.3at, IPM disabled): 23.3W

Other interfaces

• E0, E1: HPE SmartRate port (RJ-45, maximum negotiated speed 5 Gbps)

–Auto-sensing link speed (100/1000/2500/5000BASE-T) and MDI/ MDX

–2.5 Gbps and 5 Gbps speeds comply with NBase-T and 802.3bz specifications

–PoE-PD: 48Vdc (nominal) 802.3at/bt PoE (class 4 or higher)

–802.3az Energy Efficient Ethernet (EEE)

• Link Aggregation (LACP) support between both network ports for redundancy and increased capacity

• PoE power can be drawn from either port (single source, or set to prioritize) or both ports simultaneously (set to combine) When set to prioritize, the AP draws power from E0 and may failover to E1.

• DC power interface: 48Vdc (nominal, +/-5%), accepts 1.35mm/3.5mm center-positive circular plug with 9.5mm length

• USB 2.0 host interface (Type A connector)

–Capable of sourcing up to 1A/5W to an attached device

**ในกรณีไม่ได้ใช้ Switch POE ต้องซื้อ Power Adapter R3K00A หรือ Power injector R1C73A

Package Contents
● 1 x Aruba AP-534 (RW) Unified AP (JZ331A)
● 1 x Aruba Quick Start guide
●  1 x Ethernet cable

รูปแบบการรับประกัน

Limited Life Time Carry-in Warranty by HPE Thailand (หลังประกาศ EOS ยังรับประกันอีก 5 ปี)

ข้อมูลเพิ่มเติม

#AP-534 #Aruba #accesspoint #JZ331A
